    NSK Super Precision Persingers China Поставщик

    NSK Super Precision Bearings Shape
    WhatsApp: +86 15221008360
    		Граничные размеры
    		Основные рейтинги нагрузки Допустимо Эффективная нагрузка Масса Ограничивающие скорости ( 2)

    Номера подшипника
    		(мм)
    		(KN) Осевой Центр (g) (ок.) (Мин –1 )

    Нагрузка ( 1) (мм) а

    d D B r r1 C R (динамика) C или (статический) (KN)
    		Смазка Масло

    (мин) (мин)



    725с 5 16 5 0.3 0.15 1.7 0.66 0.545 3.91 4.5 110 000 167 000

    725а 5 16 5 0.3 0.15 1.61 0.62 0.665 5.53 4.5 72 000 96 000

    706c 6 17 6 0.3 0.15 2.15 0.845 0.765 4.54 5.5 100 000 153 000

    706а 6 17 6 0.3 0.15 2.03 0.795 0.725 6.32 5.5 66 000 87 000

    726c 6 19 6 0.3 0.15 2.39 1 0.835 4.67 7.8 92 000 140 000

    726а 6 19 6 0.3 0.15 2.24 0.94 0.395 6.61 7.8 60 000 80 000

    707c 7 19 6 0.3 0.15 2.39 1 0.835 4.67 7.4 89 000 135 000

    707а 7 19 6 0.3 0.15 2.24 0.94 0.375 6.61 7.4 58 000 77 000

    708c 8 22 7 0.3 0.15 3.55 1.54 1.3 5.51 12 77 000 117 000

    708а 8 22 7 0.3 0.15 3.35 1.45 1.02 7.84 12 50 000 67 000

    728с 8 24 8 0.3 0.15 3.6 1.58 1.33 6.14 16 72 000 110 000

    728а 8 24 8 0.3 0.15 3.35 1.48 0.61 8.62 16 47 000 63 000

    7900с 10 22 6 0.3 0.15 3 1.52 1.23 14.1 5.1 0.01 – 71 900 109 400
    7900A5 10 22 6 0.3 0.15 2.88 1.45 1.44 – 6.7 0.009 – 62 500 93 800
    7901c 12 24 6 0.3 0.15 3.35 1.86 1.45 14.7 5.4 0.011 – 63 900 97 300
    7901A5 12 24 6 0.3 0.15 3.2 1.77 1.71 – 7.2 0.011 – 55 600 83 400
    7902c 15 28 7 0.3 0.15 4.75 2.64 1.93 14.5 6.4 0.016 – 53 500 81 400
    7902A5 15 28 7 0.3 0.15 4.55 2.53 2.22 – 8.5 0.016 – 46 600 69 800
    7903c 17 30 7 0.3 0.15 5 2.94 2.09 14.8 6.6 0.017 – 49 000 74 500
    7903A5 17 30 7 0.3 0.15 4.75 2.8 2.21 – 9 0.017 – 42 600 63 900
    7904c 20 37 9 0.3 0.15 6.95 4.25 3.2 14.9 8.3 0.036 – 40 400 61 500
    7904A5 20 37 9 0.3 0.15 6.6 4.05 3.55 – 11.1 0.037 – 35 100 52 700
    7905c 25 42 9 0.3 0.15 7.85 5.4 3.9 15.5 9 0.043 – 34 400 52 300
    7905A5 25 42 9 0.3 0.15 7.45 5.15 4.4 – 12.3 0.043 – 29 900 44 800
    7906c 30 47 9 0.3 0.15 8.3 6.25 4.4 15.9 9.7 0.049
    		29 900 45 500
    7906A5 30 47 9 0.3 0.15 7.85 5.95 4.95 – 13.5 0.05
    		26 000 39 000
    7907c 35 55 10 0.6 0.3 12.1 9.15 6.6 15.7 11 0.074
    		25 600 38 900
    7907a5 35 55 10 0.6 0.3 11.4 8.7 7.2 – 15.5 0.075
    		22 300 33 400
    7908c 40 62 12 0.6 0.3 15.1 11.7 8.4 15.7 12.8 0.109
    		22 600 34 400
    7908A5 40 62 12 0.6 0.3 14.3 11.2 8.9 – 17.9 0.11
    		19 700 29 500
    7909c 45 68 12 0.6 0.3 16 13.4 8.55 16 13.6 0.129
    		20 400 31 000
    7909A5 45 68 12 0.6 0.3 15.1 12.7 9.95 – 19.2 0.13
    		17 700 26 600
    7910c 50 72 12 0.6 0.3 16.9 15 9.45 16.2 14.2 0.13
    		18 900 28 700
    7910A5 50 72 12 0.6 0.3 15.9 14.2 11 – 20.2 0.132
    		16 400 24 600
    7911c 55 80 13 1 0.6 19.1 17.7 11 16.3 15.5 0.182
    		17 100 26 000
    7911a5 55 80 13 1 0.6 18.1 16.8 12.5 – 22.2 0.184
    		14 900 22 300
    7912c 60 85 13 1 0.6 19.4 18.7 11.5 16.5 16.2 0.195
    		15 900 24 200
    7912A5 60 85 13 1 0.6 18.3 17.7 13 – 23.4 0.198
    		13 800 20 700
    7913c 65 90 13 1 0.6 20.2 20.5 12.5 16.7 16.9 0.208
    		14 900 22 600
    7913A5 65 90 13 1 0.6 19.1 19.4 14.2 – 24.6 0.211
    		13 000 19 400
    7914c 70 100 16 1 0.6 28.1 27.8 17.3 16.4 19.4 0.338
    		13 600 20 600
    7914A5 70 100 16 1 0.6 26.5 26.3 20.3 – 27.8 0.341
    		11 800 17 700
    7915c 75 105 16 1 0.6 28.6 29.3 18 16.6 20.1 0.358
    		12 800 19 500
    7915A5 75 105 16 1 0.6 26.9 27.7 21.2 – 29 0.355
    		11 200 16 700
    7916c 80 110 16 1 0.6 29 30.5 18.7 16.7 20.7 0.377
    		12 200 18 500
    7916A5 80 110 16 1 0.6 27.3 29 22.1 – 30.2 0.381
    		10 600 15 800
    7917c 85 120 18 1.1 0.6 39 40.5 25.9 16.5 22.7 0.534
    		11 300 17 100
    7917A5 85 120 18 1.1 0.6 36.5 38.5 30 – 32.9 0.541
    		9 800 14 700
    7918c 90 125 18 1.1 0.6 41.5 46 29.1 16.6 23.4 0.568
    		10 700 16 300
    7918A5 90 125 18 1.1 0.6 39.5 43.5 33.5 – 34.1 0.56
    		9 400 14 000
    7919c 95 130 18 1.1 0.6 42.5 48 30 16.7 24.1 0.597
    		10 300 15 600
    7919A5 95 130 18 1.1 0.6 40 45.5 35 – 35.2 0.603
    		8 900 13 400
    7920c 100 140 20 1.1 0.6 50 54 33 16.5 26.1 0.8
    		9 600 14 600
    7920A5 100 140 20 1.1 0.6 47.5 51.5 39.5 – 38 0.808
    		8 400 12 500
    7921c 105 145 20 1.1 0.6 51 57 34.5 16.6 26.7 0.831 – 9 200 14 000
    7921A5 105 145 20 1.1 0.6 48 54 41 – 39.2 0.82 – 8 000 12 000
    7922c 110 150 20 1.1 0.6 52 59.5 35.5 16.7 27.4 0.867 – 8 900 13 500
    7922A5 110 150 20 1.1 0.6 49 56 43 – 40.3 0.877 – 7 700 11 600
    7924c 120 165 22 1.1 0.6 72 81 50.5 16.5 30.1 1.16 – 8 100 12 300
    7924A5 120 165 22 1.1 0.6 67.5 77 59.5 – 44.2 1.15 – 7 100 10 600
    7926c 130 180 24 1.5 1 78.5 91 55 16.5 32.8 1.5 – 7 500 11 300
    7926A5 130 180 24 1.5 1 74 86 63.5 – 48.1 1.54 – 6 500 9 700
    7928c 140 190 24 1.5 1 79.5 95.5 58 16.7 34.1 1.63 – 7 000 10 700
    7928A5 140 190 24 1.5 1 75 90 68 – 50.5 1.63 – 6 100 9 100
    7930c 150 210 28 2 1 102 122 74 16.6 38.1 2.96 – 6 400 9 800
    7930A5 150 210 28 2 1 96.5 115 84.5 – 56 2.97 – 5 600 8 400
    7932c 160 220 28 2 1 106 133 80 16.7 39.4 3.1 – 6 100 9 300
    7932A5 160 220 28 2 1 100 125 93.5 – 58.3 3.12 – 5 300 7 900
    7934c 170 230 28 2 1 113 148 88.5 16.8 40.8 3.36 – 5 800 8 800
    7934a5 170 230 28 2 1 106 140 103 – 60.6 3.36 – 5 000 7 500
    7936c 180 250 33 2 1 145 184 111 16.6 45.3 4.9 – 5 400 8 200
    7936A5 180 250 33 2 1 137 174 127 – 66.6 4.94 – 4 700 7 000
    7938c 190 260 33 2 1 147 192 115 16.7 46.6 4.98 – 5 200 7 800
    7938A5 190 260 33 2 1 139 182 131 – 69 5.12 – 4 500 6 700
    7940c 200 280 38 2.1 1.1 189 244 144 16.5 51.2 6.85 – 4 800 7 300
    7940A5 200 280 38 2.1 1.1 178 231 169 – 75 6.92 – 4 200 6 300
    7944c 220 300 38 2.1 1.1 190 256 235 16.7 53.8 6.665 – 4 500 6 800
    7944A5 220 300 38 2.1 1.1 179 242 174 – 79.6 6.665 – 3 900 5 800
    7948c 240 320 38 2.1 1.1 200 286 260 16.8 56.5 7.224 – 4 200 6 300
    7948A5 240 320 38 2.1 1.1 189 270 193 – 84.3 7.224 – 3 600 5 400
    7952c 260 360 46 2.1 1.1 256 365 340 16.6 64.5 11.936 – 3 800 5 700
    7952A5 260 360 46 2.1 1.1 241 345 252 – 95.3 11.936 – 3 300 4 900
    7956c 280 380 46 2.1 1.1 272 410 380 16.7 67.2 12.853 – 3 500 5 400
    7956A5 280 380 46 2.1 1.1 256 390 283 – 99.9 12.853 – 3 100 4 600
    7000с 10 26 8 0.3 0.15 5.3 2.49 2.16 12.6 6.4 0.019 – 63 900 97 300
    7000A5 10 26 8 0.3 0.15 5.15 2.41 2.48 – 8.2 0.019 – 55 600 83 400
    7000а 10 26 8 0.3 0.15 5 2.34 1.91 – 9.2 0.019 – 41 700 55 600
    7001c 12 28 8 0.3 0.15 5.8 2.9 2.4 13.2 6.7 0.021 – 57 500 87 500
    7001A5 12 28 8 0.3 0.15 5.6 2.79 2.82 – 8.7 0.021 – 50 000 75 000
    7001a 12 28 8 0.3 0.15 5.4 2.71 2.13 – 9.8 0.021 – 37 500 50 000
    7002c 15 32 9 0.3 0.15 6.25 3.4 2.63 14.1 7.6 0.03 – 49 000 74 500
    7002A5 15 32 9 0.3 0.15 5.95 3.25 3.05 – 10 0.03 – 42 600 63 900
    7002а 15 32 9 0.3 0.15 5.8 3.15 2.36 – 11.3 0.03 – 32 000 42 600
    7003c 17 35 10 0.3 0.15 6.6 3.8 2.85 14.5 8.5 0.039 – 44 300 67 400
    7003a5 17 35 10 0.3 0.15 6.3 3.65 3.35 – 11.1 0.04 – 38 500 57 700
    7003а 17 35 10 0.3 0.15 6.1 3.5 2.59 – 12.5 0.04 – 28 900 38 500
    7004c 20 42 12 0.6 0.3 11.1 6.55 4.8 14 10.1 0.067 – 37 100 56 500
    7004A5 20 42 12 0.6 0.3 10.6 6.25 5.45 – 13.2 0.067 – 32 300 48 400
    7004a 20 42 12 0.6 0.3 10.3 6.1 4.2 – 14.9 0.068 – 24 200 32 300
    7005c 25 47 12 0.6 0.3 11.7 7.4 5.2 14.7 10.8 0.078 – 32 000 48 700
    7005A5 25 47 12 0.6 0.3 11.1 7.1 5.95 – 14.4 0.077 – 27 800 41 700
    7005а 25 47 12 0.6 0.3 10.7 6.85 4.55 – 16.4 0.079 – 20 900 27 800
    7006c 30 55 13 1 0.6 15.1 10.3 6.85 14.9 12.2 0.114
    		27 100 41 200
    7006A5 30 55 13 1 0.6 14.4 9.8 8.05 – 16.4 0.114
    		23 600 35 300
    7006a 30 55 13 1 0.6 13.9 9.45 6.2 – 18.8 0.116
    		17 700 23 600
    7007c 35 62 14 1 0.6 19.1 13.7 9.35 15 13.5 0.151
    		23 800 36 100
    7007a5 35 62 14 1 0.6 18.2 13 11.4 – 18.3 0.151
    		20 700 31 000
    7007а 35 62 14 1 0.6 17.5 12.6 8.75 – 21 0.153
    		15 500 20 700
    7008c 40 68 15 1 0.6 20.6 15.9 10.6 15.4 14.7 0.189
    		21 300 32 500
    7008A5 40 68 15 1 0.6 19.5 15.1 12 – 20.1 0.188
    		18 600 27 800
    7008а 40 68 15 1 0.6 18.8 14.6 9.15 – 23.1 0.191
    		13 900 18 600
    7009с 45 75 16 1 0.6 24.4 19.3 12.4 15.4 16 0.238
    		19 200 29 200
    7009A5 45 75 16 1 0.6 23.1 18.3 14.5 – 22 0.25
    		16 700 25 000
    7009а 45 75 16 1 0.6 22.3 17.7 11.1 – 25.3 0.241
    		12 500 16 700
    7010c 50 80 16 1 0.6 26 21.9 13.9 15.7 16.7 0.259
    		17 700 27 000
    7010A5 50 80 16 1 0.6 24.6 20.8 16.2 – 23.2 0.27
    		15 400 23 100
    7010a 50 80 16 1 0.6 23.7 20.1 12.5 – 26.8 0.262
    		11 600 15 400
    7011c 55 90 18 1.1 0.6 34 28.6 18.9 15.5 18.7 0.38
    		15 900 24 200
    7011a5 55 90 18 1.1 0.6 32.5 27.2 21.8 – 25.9 0.383
    		13 800 20 700
    7011a 55 90 18 1.1 0.6 31 26.3 16.6 – 29.9 0.385
    		10 400 13 800
    7012c 60 95 18 1.1 0.6 35 30.5 19.9 15.7 19.4 0.405
    		14 900 22 600
    7012A5 60 95 18 1.1 0.6 33 29.1 23 – 27.1 0.408
    		13 000 19 400
    7012a 60 95 18 1.1 0.6 32 28.1 17.6 – 31.4 0.41
    		9 700 13 000
    7013c 65 100 18 1.1 0.6 37 34.5 22 15.9 20 0.435
    		14 000 21 300
    7013A5 65 100 18 1.1 0.6 35 32.5 25.4 – 28.2 0.455
    		12 200 18 200
    7013a 65 100 18 1.1 0.6 33.5 31.5 19.5 – 32.8 0.441
    		9 100 12 200
    7014c 70 110 20 1.1 0.6 47 43 26.8 15.7 22.1 0.606
    		12 800 19 500
    7014A5 70 110 20 1.1 0.6 44.5 41 32 – 31 0.625
    		11 200 16 700
    7014a 70 110 20 1.1 0.6 42.5 39.5 24.6 – 36 0.613
    		8 400 11 200
    7015c 75 115 20 1.1 0.6 48 45.5 28.1 15.9 22.7 0.643
    		12 200 18 500
    7015A5 75 115 20 1.1 0.6 45.5 43.5 33.5 – 32.1 0.652
    		10 600 15 800
    7015a 75 115 20 1.1 0.6 43.5 41.5 25.9 – 37.4 0.65
    		7 900 10 600
    7016c 80 125 22 1.1 0.6 58.5 55.5 34.5 15.7 24.7 0.855
    		11 300 17 100
    7016A5 80 125 22 1.1 0.6 55.5 52.5 41 – 34.9 0.88
    		9 800 14 700
    7016a 80 125 22 1.1 0.6 53.5 50.5 31.5 – 40.6 0.864
    		7 400 9 800
    7017c 85 130 22 1.1 0.6 60 58.5 38 15.9 25.4 0.898
    		10 700 16 300
    7017A5 85 130 22 1.1 0.6 57 55.5 43 – 36.1 0.904
    		9 400 14 000
    7017a 85 130 22 1.1 0.6 54.5 53.5 33 – 42 0.907
    		7 000 9 400
    7018c 90 140 24 1.5 1 71.5 69 44.5 15.7 27.4 1.16
    		10 000 15 300
    7018A5 90 140 24 1.5 1 68 65.5 52 – 38.8 1.17
    		8 700 13 100
    7018a 90 140 24 1.5 1 65 63.5 40.5 – 45.2 1.18
    		6 600 8 700
    7019c 95 145 24 1.5 1 73.5 73 47 15.9 28.1 1.21
    		9 600 14 600
    7019A5 95 145 24 1.5 1 69.5 69.5 52.5 – 40 1.41
    		8 400 12 500
    7019a 95 145 24 1.5 1 67 67 40.5 – 46.6 1.23
    		6 300 8 400
    7020c 100 150 24 1.5 1 75.5 77 49 16 28.7 1.27
    		9 200 14 000
    7020A5 100 150 24 1.5 1 71 73.5 57.5 – 41.1 1.45
    		8 000 12 000
    7020a 100 150 24 1.5 1 68.5 70.5 44.5 – 48.1 1.28
    		6 000 8 000
    7021c 105 160 26 2 1 88 89.5 57 15.9 30.7 1.58 – 8 700 13 300
    7021A5 105 160 26 2 1 83.5 85 66.5 – 43.9 1.82 – 7 600 11 400
    7021a 105 160 26 2 1 80 81.5 51 – 51.2 1.6 – 5 700 7 600
    7022c 110 170 28 2 1 106 104 68.5 15.6 32.7 1.94 – 8 300 12 500
    7022A5 110 170 28 2 1 100 99 79.5 – 46.6 2.26 – 7 200 10 800
    7022a 110 170 28 2 1 96.5 95.5 61 – 54.4 1.96 – 5 400 7 200
    7024c 120 180 28 2 1 112 117 75.5 15.8 34.1 2.09 – 7 700 11 700
    7026c 130 200 33 2 1 129 137 86 15.9 38.6 3.22 – 7 000 10 700
    7026A5 130 200 33 2 1 122 130 99.5 – 55 3.66 – 6 100 9 100
    7026a 130 200 33 2 1 117 125 76.5 – 64.1 3.26 – 4 600 6 100
    7028c 140 210 33 2 1 132 145 90 16 39.9 3.41 – 6 600 10 000
    7028A5 140 210 33 2 1 125 138 104 – 57.3 3.87 – 5 800 8 600
    7028a 140 210 33 2 1 120 133 80.5 – 67 3.44 – 4 300 5 800
    7030c 150 225 35 2.1 1.1 151 168 105 16 42.6 4.15 – 6 200 9 400
    7030A5 150 225 35 2.1 1.1 143 160 123 – 61.2 4.69 – 5 400 8 000
    7030а 150 225 35 2.1 1.1 137 154 95 – 71.6 4.19 – 4 000 5 400
    7032c 160 240 38 2.1 1.1 171 193 118 16 45.8 5.11 – 5 800 8 800
    7032A5 160 240 38 2.1 1.1 162 183 138 – 65.6 5.71 – 5 000 7 500
    7032a 160 240 38 2.1 1.1 155 176 106 – 76.7 5.16 – 3 800 5 000
    7034c 170 260 42 2.1 1.1 205 234 149 15.9 49.8 6.88 – 5 400 8 200
    7034A5 170 260 42 2.1 1.1 193 223 168 – 71.1 7.83 – 4 700 7 000
    7034a 170 260 42 2.1 1.1 186 214 129 – 83.1 6.94 – 3 500 4 700
    7036c 180 280 46 2.1 1.1 228 276 175 15.8 53.8 10.4 – 5 000 7 700
    7036A5 180 280 46 2.1 1.1 216 262 195 – 76.6 10.4 – 4 400 6 600
    7036A 180 280 46 2.1 1.1 207 252 151 – 89.4 9.27 – 3 300 4 400
    7038c 190 290 46 2.1 1.1 247 305 192 15.9 55.2 11.2 – 4 800 7 300
    7038A5 190 290 46 2.1 1.1 233 291 222 – 79 11.2 – 4 200 6 300
    7038a 190 290 46 2.1 1.1 224 280 172 – 92.3 11.3 – 3 200 4 200
    7040c 200 310 51 2.1 1.1 265 340 213 15.9 59.7 13.6 – 4 600 6 900
    7200с 10 30 9 0.6 0.3 5.4 2.61 2.16 13.2 7.2 0.032 57 500 87 500
    7200A5 10 30 9 0.6 0.3 5.2 2.51 2.49 – 9.2 0.031 50 000 75 000
    7200а 10 30 9 0.6 0.3 5.05 2.44 1.92 – 10.3 0.032 37 500 50 000
    7201c 12 32 10 0.6 0.3 7.9 3.85 3.45 12.5 7.9 0.036 52 300 79 600
    7201a5 12 32 10 0.6 0.3 7.65 3.7 3.55 – 10.1 0.036 45 500 68 200
    7201a 12 32 10 0.6 0.3 7.45 3.65 2.72 – 11.4 0.03 34 100 45 500
    7202c 15 35 11 0.6 0.3 8.65 4.55 3.85 13.2 8.8 0.045 46 000 70 000
    7202A5 15 35 11 0.6 0.3 8.35 4.35 3.95 – 11.3 0.044 40 000 60 000
    7202а 15 35 11 0.6 0.3 8.1 4.25 3 – 12.7 0.045 30 000 40 000
    7203c 17 40 12 0.6 0.3 10.9 5.85 4.85 13.3 9.8 0.065 40 400 61 500
    7203A5 17 40 12 0.6 0.3 10.4 5.6 5.3 – 12.6 0.064 35 100 52 700
    7203а 17 40 12 0.6 0.3 10.1 5.45 4.05 – 14.2 0.065 26 400 35 100
    7204c 20 47 14 1 0.6 14.6 8.05 6.3 13.3 11.5 0.103 34 400 52 300
    7204A5 20 47 14 1 0.6 14 7.75 7.4 – 14.8 0.102 29 900 44 800
    7204a 20 47 14 1 0.6 13.6 7.55 5.75 – 16.7 0.104 22 400 29 900
    7205с 25 52 15 1 0.6 16.6 10.2 7.5 14 12.7 0.127 29 900 45 500
    7205A5 25 52 15 1 0.6 15.9 9.8 9.05 – 16.5 0.13 26 000 39 000
    7205а 25 52 15 1 0.6 15.4 9.45 6.95 – 18.6 0.129 19 500 26 000
    7206с 30 62 16 1 0.6 23 14.7 10.3 13.9 14.2 0.194 25 000 38 100
    7206A5 30 62 16 1 0.6 22.1 14.1 12 – 18.7 0.194 21 800 32 700
    7206а 30 62 16 1 0.6 21.3 13.6 9.2 – 21.3 0.197 16 400 21 800
    7207c 35 72 17 1.1 0.6 30.5 19.9 14.4 13.9 15.7 0.28 21 500 32 800
    7207A5 35 72 17 1.1 0.6 29.1 19.1 16.6 – 21 0.277 18 700 28 100
    7207а 35 72 17 1.1 0.6 28.2 18.5 12.7 – 23.9 0.284 14 100 18 700
    7208с 40 80 18 1.1 0.6 36.5 25.2 17.6 14.1 17 0.366 19 200 29 200
    7208A5 40 80 18 1.1 0.6 34.5 24.1 20.6 – 23 0.362 16 700 25 000
    7208а 40 80 18 1.1 0.6 33.5 23.3 15.8 – 26.3 0.37 12 500 16 700
    7209с 45 85 19 1.1 0.6 41 28.8 19.6 14.2 18.2 0.406 17 700 27 000
    7209A5 45 85 19 1.1 0.6 39 27.6 23.3 – 24.7 0.402 15 400 23 100
    7209а 45 85 19 1.1 0.6 37.5 26.7 18 – 28.3 0.41 11 600 15 400
    7210c 50 90 20 1.1 0.6 43 31.5 21.1 14.5 19.4 0.457 16 500 25 000
    7210A5 50 90 20 1.1 0.6 41 30.5 25.2 – 26.3 0.453 14 300 21 500
    7210a 50 90 20 1.1 0.6 39.5 29.3 19.4 – 30.2 0.462 10 800 14 300
    7211c 55 100 21 1.5 1 53 40 27.6 14.5 20.9 0.601 14 900 22 600
    7211A5 55 100 21 1.5 1 50.5 38 32.5 – 28.6 0.596 13 000 19 400
    7211a 55 100 21 1.5 1 49 37 25 – 32.9 0.609 9 700 13 000
    7212c 60 110 22 1.5 1 64 49 34 14.4 22.4 0.78 13 600 20 600
    7212A5 60 110 22 1.5 1 61 47 40 – 30.8 0.773 11 800 17 700
    7212A 60 110 22 1.5 1 59 45.5 30.5 – 35.5 0.789 8 900 11 800
    7213c 65 120 23 1.5 1 73 58.5 40 14.6 23.9 1.01 12 500 19 000
    7213A5 65 120 23 1.5 1 69.5 56 46.5 – 33.1 1 10 900 16 300
    7213A 65 120 23 1.5 1 67.5 54 36 – 38.2 1.02 8 200 10 900
    7214c 70 125 24 1.5 1 79.5 64.5 43 14.6 25.1 1.09 11 800 18 000
    7214A5 70 125 24 1.5 1 76 61.5 49.5 – 34.7 1.08 10 300 15 400
    7214а 70 125 24 1.5 1 73 59.5 38 – 40.1 1.1 7 700 10 300
    7215c 75 130 25 1.5 1 83 70 46 14.8 26.2 1.19 11 300 17 100
    7215A5 75 130 25 1.5 1 79 66.5 53 – 36.4 1.18 9 800 14 700
    7215а 75 130 25 1.5 1 76 64.5 40.5 – 42.1 1.2 7 400 9 800
    7216c 80 140 26 2 1 93 77.5 54.5 14.7 27.7 1.43 10 500 16 000
    7216A5 80 140 26 2 1 88.5 74 62 – 38.6 1.42 9 100 13 700
    7216a 80 140 26 2 1 85.5 71.5 47.5 – 44.8 1.45 6 900 9 100
    7217c 85 150 28 2 1 107 90.5 60.5 14.7 29.7 1.79 9 800 14 900
    7217A5 85 150 28 2 1 102 86.5 70 – 41.4 1.79 8 600 12 800
    7217a 85 150 28 2 1 98.5 83.5 53.5 – 47.9 1.8 6 400 8 600
    7218c 90 160 30 2 1 123 105 72 14.6 31.7 2.2 9 200 14 000
    7218A5 90 160 30 2 1 117 100 83.5 – 44.1 2.31 8 000 12 000
    7218a 90 160 30 2 1 113 96.5 64.5 – 51.1 2.23 6 000 8 000
    7219c 95 170 32 2.1 1.1 133 112 76 14.6 33.7 2.64 8 700 13 300
    7219A5 95 170 32 2.1 1.1 127 107 87 – 46.9 2.63 7 600 11 400
    7219а 95 170 32 2.1 1.1 122 103 67 – 54.2 2.67 5 700 7 600
    7220c 100 180 34 2.1 1.1 149 127 88.5 14.5 35.7 3.18 8 300 12 500
    7220A5 100 180 34 2.1 1.1 142 121 103 – 49.6 3.16 7 200 10 800
    7220a 100 180 34 2.1 1.1 137 117 79.5 – 57.4 3.21 5 400 7 200
    7221c 105 190 36 2.1 1.1 162 143 97.5 14.5 37.7 3.78 7 800 11 900
    7221A5 105 190 36 2.1 1.1 155 137 111 – 52.4 3.77 6 800 10 200
    7221a 105 190 36 2.1 1.1 150 132 85 – 60.6 3.82 5 100 6 800
    7222c 110 200 38 2.1 1.1 176 160 108 14.5 39.8 4.45 7 500 11 300
    7222A5 110 200 38 2.1 1.1 168 153 126 – 55.1 4.45 6 500 9 700
    7222A 110 200 38 2.1 1.1 162 148 97 – 63.7 4.49 4 900 6 500
    7224c 120 215 40 2.1 1.1 199 192 132 14.6 42.4 5.42 6 900 10 500
    7224A5 120 215 40 2.1 1.1 189 184 150 – 59.1 5.42 6 000 9 000
    7224а 120 215 40 2.1 1.1 183 177 116 – 68.3 5.45 4 500 6 000
    7226c 130 230 40 3 1.1 206 209 144 14.9 44.1 6.23 6 400 9 800
    7226A5 130 230 40 3 1.1 196 199 163 – 62 6.22 5 600 8 400
    7226a 130 230 40 3 1.1 189 193 127 – 72 6.28 4 200 5 600
    7228c 140 250 42 3 1.1 238 254 172 14.8 47.1 7.91 5 900 9 000
    7228A5 140 250 42 3 1.1 226 242 194 – 66.5 7.91 5 200 7 700
    7228a 140 250 42 3 1.1 218 234 150 – 77.3 7.97 3 900 5 200
    7230c 150 270 45 3 1.1 270 305 205 14.7 50.6 11.1 5 500 8 400
    7230A5 150 270 45 3 1.1 258 290 231 – 71.5 11.1 4 800 7 200
    7230A 150 270 45 3 1.1 248 280 179 – 83.1 11.2 3 600 4 800
    25bnr19s 25 42 9 0.3 0.15 5.95 3.5 4.95 9.9 0.042 – 800 800
    25bnr19h 25 42 9 0.3 0.15 3.25 0.038 – 800 600
    25bnr19x 25 42 9 0.3 0.15 0.038 – 700 600
    25ber19s 25 42 9 0.3 0.15 5.7 3.4 5.9 12.3 0.042 – 900 800
    25ber19h 25 42 9 0.3 0.15 3.95 0.038 – 800 700
    25ber19x 25 42 9 0.3 0.15 0.038 – 800 600
    30bnr19s 30 47 9 0.3 0.15 6.3 4.05 5.75 10.8 0.048
    		400 0

    30bnr19h 30 47 9 0.3 0.15 3.8 0.043 800 800

    30bnr19x 30 47 9 0.3 0.15 0.043 600 800

    30ber19s 30 47 9 0.3 0.15 6 3.9 6.8 13.5 0.048 200 200

    30ber19h 30 47 9 0.3 0.15 4.6 0.043 600 0

    30ber19x 30 47 9 0.3 0.15 0.043 400 0

    35BNR19S 35 55 10 0.6 0.3 9.2 6 8.55 12.3 0.072 200 500

    35BNR19H 35 55 10 0.6 0.3 5.6 0.063 0 300

    35bnr19x 35 55 10 0.6 0.3 0.063 700 400

    35ber19s 35 55 10 0.6 0.3 8.8 5.75 10 15.5 0.072
    		700 800
    35ber19h 35 55 10 0.6 0.3 6.8 0.063
    		600 600
    35ber19x 35 55 10 0.6 0.3 0.063
    		300 700
    40bnr19s 40 62 12 0.6 0.3 11.5 7.65 10.8 14.3 0.105
    		500 300
    40bnr19h 40 62 12 0.6 0.3 7.1 0.092
    		300 0
    40bnr19x 40 62 12 0.6 0.3 0.092
    		200 800
    40ber19s 40 62 12 0.6 0.3 11 7.35 12.8 17.9 0.105
    		600 400
    40ber19h 40 62 12 0.6 0.3 8.65 0.092
    		400 100
    40ber19x 40 62 12 0.6 0.3 0.092
    		300 900
    45bnr19s 45 68 12 0.6 0.3 12.1 8.7 12.4 15.2 0.125
    		800 400
    45bnr19h 45 68 12 0.6 0.3 8.1 0.111
    		900 600

    45bnr19x 45 68 12 0.6 0.3 0.111
    		200 500
    45ber19s 45 68 12 0.6 0.3 11.6 8.35 14.6 19.2 0.125
    		300 100

    45ber19h 45 68 12 0.6 0.3 9.85 0.111 400 300

    45ber19x 45 68 12 0.6 0.3 0.111 700 100

    50bnr19s 50 72 12 0.6 0.3 12.8 9.75 13.9 15.9 0.127 0 800

    50bnr19h 50 72 12 0.6 0.3 9.1 0.111
    		600 0
    55bnr19s 55 80 13 1 0.6 14.4 11.4 16.2 17.5 0.178
    		800 700
    55BNR19H 55 80 13 1 0.6 10.6 0.158
    		700 500
    55bnr19x 55 80 13 1 0.6 0.158
    		200 900
    55ber19s 55 80 13 1 0.6 13.8 10.9 16.1 22.2 0.178
    		800 200
    55ber19h 55 80 13 1 0.6 12.9 0.158
    		800 100
    55ber19x 55 80 13 1 0.6 0.158
    		200 500

    60bnr19s 60 85 13 1 0.6 14.6 12 17.1 18.3 0.19 400 600

    60bnr19h 60 85 13 1 0.6 11.2 0.17 900 700

    60bnr19x 60 85 13 1 0.6 0.17 0 600

    60ber19s 60 85 13 1 0.6 14 11.5 20.1 23.4 0.19 600 500

    60ber19h 60 85 13 1 0.6 13.6 0.17 100 500

    60ber19x 60 85 13 1 0.6 0.17 300 400

    65bnr19s 65 90 13 1 0.6 15.2 13.2 18.7 19.1 0.204 100 900

    65bnr19h 65 90 13 1 0.6 12.3 0.181 300 200

    65bnr19x 65 90 13 1 0.6 0.181 100 600

    65ber19s 65 90 13 1 0.6 14.5 12.6 22.1 24.6 0.204
    		500 0
    65ber19h 65 90 13 1 0.6 14.9 0.181
    		700 300
    65ber19x 65 90 13 1 0.6 0.181
    		600 800
    70bnr19s 70 100 16 1 0.6 21.3 18.1 26.1 21.8 0.328
    		500 600
    70bnr19h 70 100 16 1 0.6 17.1 0.292
    		200 0
    70bnr19x 70 100 16 1 0.6 0.292
    		800 900
    70ber19s 70 100 16 1 0.6 20.4 17.3 30.5 27.8 0.328
    		200 0
    70ber19h 70 100 16 1 0.6 20.7 0.292
    		900 500
    70ber19x 70 100 16 1 0.6 0.292
    		400 300

    75bnr19s 75 105 16 1 0.6 21.6 19 27.5 22.6 0.348
    		600 300
    75bnr19h 75 105 16 1 0.6 18 0.31
    		0 200

    75bnr19x 75 105 16 1 0.6 0.31 400 700

    75ber19s 75 105 16 1 0.6 20.7 18.2 32.5 29 0.348 400 900

    75ber19h 75 105 16 1 0.6 21.7 0.31 800 800

    75ber19x 75 105 16 1 0.6 0.31 200 400

    80bnr19s 80 110 16 1 0.6 22 19.9 28.9 23.4 0.366
    		800 100
    85bnr19s 85 120 18 1.1 0.6 29.4 26.3 38 25.7 0.527
    		13 700 19 600
    85bnr19h 85 120 18 1.1 0.6 24.8 0.456
    		17 600 27 400











    85bnr19x 85 120 18 1.1 0.6



    		0.456
    		20 500 32 200
    85ber19s 85 120 18 1.1 0.6 28.1 25.2 35.5 32.9 0.527
    		11 800 16 600
    85ber19h 85 120 18 1.1 0.6 30 0.456
    		15 700 24 400











    85ber19x 85 120 18 1.1 0.6



    		0.456
    		18 600 29 300
    90bnr19s 90 125 18 1.1 0.6 31.5 29.7 43 26.5 0.552
    		13 100 18 700
    90bnr19h 90 125 18 1.1 0.6 28.1 0.48
    		16 800 26 100











    90bnr19x 90 125 18 1.1 0.6



    		0.48
    		19 600 30 700
    90ber19s 90 125 18 1.1 0.6 30 28.5 50.5 34.1 0.552
    		11 200 15 900
    90ber19h 90 125 18 1.1 0.6 34 0.48
    		14 900 23 300











    90ber19x 90 125 18 1.1 0.6



    		0.48
    		17 700 28 000
    95bnr19s 95 130 18 1.1 0.6 32 31 50 28.3 0.571
    		12 500 17 800
    95bnr19h 95 130 18 1.1 0.6 32.5 0.497
    		16 000 24 900











    95bnr19x 95 130 18 1.1 0.6



    		0.497
    		18 700 29 400
    95ber19s 95 130 18 1.1 0.6 30.5 29.7 58.5 36.7 0.571
    		10 700 15 200
    95ber19h 95 130 18 1.1 0.6 39.5 0.497
    		14 300 22 300











    95ber19x 95 130 18 1.1 0.6



    		0.497
    		16 900 26 700
    100bnr19s 100 140 20 1.1 0.6 38 35 50.5 29.5 0.571
    		11 700 16 700
    100bnr19h 100 140 20 1.1 0.6 33 0.497
    		15 000 23 400











    100bnr19x 100 140 20 1.1 0.6



    		0.497
    		17 500 27 500
    100ber19s 100 140 20 1.1 0.6 36 33.5 59.5 38 0.77
    		10 000 14 200
    100ber19h 100 140 20 1.1 0.6 40 0.673
    		13 400 20 900










    100ber19x 100 140 20 1.1 0.6



    		0.673
    		15 900 25 000
    105bnr19s 105 145 20 1.1 0.6 38.5 36.5 53 31.5 0.795 – 11 200 16 000
    105bnr19h 105 145 20 1.1 0.6 39 0.693 – 14 400 22 400











    105bnr19x 105 145 20 1.1 0.6



    		0.693 – 16 800 26 400
    105ber19s 105 145 20 1.1 0.6 37 35 62 40.9 0.795 – 9 600 13 600
    105ber19h 105 145 20 1.1 0.6 42 0.693 – 12 800 20 000











    105ber19x 105 145 20 1.1 0.6



    		0.693 – 15 200 24 000
    110bnr19s 110 150 20 1.1 0.6 39 38 55.5





    110bnr19h 110 150 20 1.1 0.6 42

















    110bnr19x 110 150 20 1.1 0.6








    110ber19s 110 150 20 1.1 0.6 37.5 36.5 65





    110ber19h 110 150 20 1.1 0.6 44

















    110ber19x 110 150 20 1.1 0.6








    120bnr19s 120 165 22 1.1 0.6 54 52 75





    120bnr19h 120 165 22 1.1 0.6 49

















    120bnr19x 120 165 22 1.1 0.6








    120ber19s 120 165 22 1.1 0.6 51.5 50 88





    120ber19h 120 165 22 1.1 0.6 59.5





    120ber19x 120 165 22 1.1 0.6



    		0.949 – 13 400 21 100
    130bnr19s 130 180 24 1.5 1

    		85
    		1.477 – 9 100 13 000






    		59.5 58.5
    		37.2




    130bnr19h 130 180 24 1.5 1 56 1.265 – 11 700 18 100
    130ber19s 130 180 24 1.5 1

    		100
    		1.477 – 7 800 11 000






    		57 56.5
    		48.1




    130ber19h 130 180 24 1.5 1 67.5 1.265 – 10 400 16 200
    140bnr19s 140 190 24 1.5 1

    		89.5
    		1.567 – 8 500 12 200






    		60 61.5
    		38.8




    140bnr19h 140 190 24 1.5 1 58.5 1.353 – 11 000 17 000
    140ber19s 140 190 24 1.5 1

    		105
    		1.567 – 7 300 10 400






    		57.5 59
    		50.5




    140ber19h 140 190 24 1.5 1 70.5 1.353 – 9 700 15 200
    150bnr19s 150 210 28 2 1

    		114
    		2.459 – 7 800 11 200






    		77 78.5
    		43.2




    150bnr19h 150 210 28 2 1 75 2.139 – 10 000 15 600
    150ber19s 150 210 28 2 1

    		134
    		2.459 – 6 700 9 500






    		73.5 75.5
    		55.9




    150ber19h 150 210 28 2 1 90.5 2.139 – 8 900 13 900
    30bnr10s 30 55 13 1 0.6 8.65 5.75 8.2 13.3 0.124
    		33 000 47 100
    30bnr10h 30 55 13 1 0.6 5.35 0.116
    		42 400 65 900
    30bnr10x 30 55 13 1 0.6 0.116
    		49 500 77 700
    30ber10s 30 55 13 1 0.6 8.3 5.5 9.65 16.3 0.124
    		28 300 40 000
    30ber10h 30 55 13 1 0.6 6.5 0.116
    		37 700 58 900
    30ber10x 30 55 13 1 0.6 0.116
    		44 800 70 600
    35bnr10s 35 62 14 1 0.6 10.1 7.1 10.2 14.8 0.164
    		28 900 41 300
    35BNR10H 35 62 14 1 0.6 6.7 0.154
    		37 200 57 800
    35bnr10x 35 62 14 1 0.6 0.154
    		43 300 68 100
    35BERT10S 35 62 14 1 0.6 9.7 6.85 12 18.2 0.164
    		24 800 35 100
    35ber10h 35 62 14 1 0.6 8.1 0.154
    		33 000 51 600
    35ber10x 35 62 14 1 0.6 0.154
    		39 200 61 900
    40bnr10s 40 68 15 1 0.6 10.6 7.95 11.5 16.2 0.204
    		26 000 37 100
    40bnr10h 40 68 15 1 0.6 7.5 0.193
    		33 400 51 900
    40bnr10x 40 68 15 1 0.6 0.193
    		38 900 61 200
    40ber10s 40 68 15 1 0.6 10.1 7.65 13.5 19.9 0.204
    		22 300 31 500
    40ber10h 40 68 15 1 0.6 9.1 0.193
    		29 700 46 300
    40ber10x 40 68 15 1 0.6 0.193
    		35 200 55 600
    45bnr10s 45 75 16 1 0.6 11.7 9 12.7 17.6 0.259
    		23 400 33 400
    45bnr10h 45 75 16 1 0.6 8.35 0.246
    		30 000 46 700
    45bnr10x 45 75 16 1 0.6 0.246
    		35 000 55 000
    45bers10s 45 75 16 1 0.6 11.2 8.6 15 21.8 0.259
    		20 000 28 400
    45ber10h 45 75 16 1 0.6 10.1 0.246
    		26 700 41 700
    45ber10x 45 75 16 1 0.6 0.246
    		31 700 50 000
    50bnr10s 50 80 16 1 0.6 12.2 9.9 14 18.4 0.281
    		21 600 30 800
    50bnr10h 50 80 16 1 0.6 9.2 0.266
    		27 700 43 100
    50bnr10x 50 80 16 1 0.6 0.266
    		32 400 50 800
    50bers10s 50 80 16 1 0.6 11.6 9.5 16.5 23 0.281
    		18 500 26 200
    50ber10h 50 80 16 1 0.6 11.1 0.266
    		24 700 38 500
    50ber10x 50 80 16 1 0.6 0.266
    		29 300 46 200
    55bnr10s 55 90 18 1.1 0.6 15.1 12.5 17.8 20.6 0.414
    		19400 27600
    55BNR10H 55 90 18 1.1 0.6 11.7 0.393
    		24 900 38 700
    55bnr10x 55 90 18 1.1 0.6 0.393
    		29 000 45 600
    55bers10s 55 90 18 1.1 0.6 14.4 12 21 25.7 0.414
    		16 600 23 500
    55ber10h 55 90 18 1.1 0.6 14.1 0.393
    		22 100 34 500
    55ber10x 55 90 18 1.1 0.6 0.393
    		26 300 41 400
    60bnr10s 60 95 18 1.1 0.6 15.6 13.7 19.5 21.5 0.443
    		18 100 25 900
    60bnr10h 60 95 18 1.1 0.6 12.8 0.419
    		23 300 36 200
    60bnr10x 60 95 18 1.1 0.6 0.419
    		27 100 42 600
    60bers10s 60 95 18 1.1 0.6 15 13.1 22.9 26.9 0.443
    		15 500 22 000
    60ber10h 60 95 18 1.1 0.6 15.5 0.419
    		20 700 32 300
    60ber10x 60 95 18 1.1 0.6 0.419
    		24 600 38 800
    65bnr10s 65 100 18 1.1 0.6 16.2 14.8 21.1 22.3 0.472
    		17 000 24 300
    65bnr10h 65 100 18 1.1 0.6 13.9 0.447
    		21 900 34 000
    65bnr10x 65 100 18 1.1 0.6 0.447
    		25 500 40 000
    65bers10s 65 100 18 1.1 0.6 15.5 14.2 24.9 28 0.472
    		14 600 20 700
    65ber10h 65 100 18 1.1 0.6 16.8 0.447
    		19 400 30 400
    65ber10x 65 100 18 1.1 0.6 0.447
    		23 100 36 400
    70bnr10s 70 110 20 1.1 0.6 22.3 19.8 28.6 24.5 0.645
    		15 600 22 300
    70bnr10h 70 110 20 1.1 0.6 18.8 0.605
    		20 000 31 200
    70bnr10x 70 110 20 1.1 0.6 0.605
    		23 400 36 700
    70bers10s 70 110 20 1.1 0.6 21.3 18.9 33.5 30.8 0.645
    		13 400 18 900
    70ber10h 70 110 20 1.1 0.6 22.6 0.605
    		17 800 27 800
    70ber10x 70 110 20 1.1 0.6 0.605
    		21 200 33 400
    75bnr10s 75 115 20 1.1 0.6 22.6 20.7 30 25.3 0.679
    		14 800 21 100
    75bnr10h 75 115 20 1.1 0.6 19.7 0.638
    		19 000 29 500
    75bnr10x 75 115 20 1.1 0.6 0.638
    		22 200 34 800
    75bers10s 75 115 20 1.1 0.6 21.6 19.8 35 31.9 0.679
    		12 700 17 900
    75ber10h 75 115 20 1.1 0.6 23.7 0.638
    		16 900 26 400
    75ber10x 75 115 20 1.1 0.6 0.638
    		20 000 31 600
    80bnr10s 80 125 22 1.1 0.6 26.5 24.5 35.5 27.5 0.921
    		13 700 19 600
    80bnr10h 80 125 22 1.1 0.6 23.4 0.867
    		17 600 27 400
    80bnr10x 80 125 22 1.1 0.6 0.867
    		20 500 32 200
    80bers10s 80 125 22 1.1 0.6 25.3 23.5 42 34.6 0.921
    		11 800 16 600
    80ber10h 80 125 22 1.1 0.6 28.2 0.867
    		15 700 24 400
    80ber10x 80 125 22 1.1 0.6 0.867
    		18 600 29 300
    85bnr10s 85 130 22 1.1 0.6 26.8 25.7 37.5 28.4 0.962
    		13 100 18 700
    85bnr10h 85 130 22 1.1 0.6 24.5 0.906
    		16 800 26 100











    85bnr10x 85 130 22 1.1 0.6



    		0.906
    		19 600 30 700
    85ber10s 85 130 22 1.1 0.6 25.6 24.6 43.5 36.1 0.962
    		11 200 15 900
    85ber10h 85 130 22 1.1 0.6 29.5 0.906
    		14 900 23 300











    85ber10x 85 130 22 1.1 0.6



    		0.906
    		17 700 28 000
    90bnr10s 90 140 24 1.5 1 35 33 48 30.7 1.241
    		12 200 17 400
    90bnr10h 90 140 24 1.5 1 31.5 1.155
    		15 700 24 400











    90bnr10x 90 140 24 1.5 1



    		1.155
    		18 300 28 700
    90ber10s 90 140 24 1.5 1 33.5 31.5 56 38.8 1.241
    		10 500 14 800
    90ber10h 90 140 24 1.5 1 38 1.155
    		14 000 21 800











    90ber10x 90 140 24 1.5 1



    		1.155
    		16 600 26 100
    95bnr10s 95 145 24 1.5 1 35.5 34.5 50 31.3 1.298
    		11 700 16 700
    95bnr10h 95 145 24 1.5 1 32.5 1.209
    		15 000 23 400











    95bnr10x 95 145 24 1.5 1



    		1.209
    		17 500 27 500
    95bers10s 95 145 24 1.5 1 34 33 58.5 39.7 1.298
    		10 000 14 200
    95ber10h 95 145 24 1.5 1 39.5 1.209
    		13 400 20 900











    95ber10x 95 145 24 1.5 1



    		1.209
    		15 900 25 000
    100bnr10s 100 150 24 1.5 1 36 36 52 32.3 1.245
    		11 200 16 000
    100bnr10h 100 150 24 1.5 1 34 1.253
    		14 400 22 400











    100bnr10x 100 150 24 1.5 1



    		1.253
    		16 800 26 400
    100bers10s 100 150 24 1.5 1 34.5 34.5 61 41.2 1.245
    		9 600 13 600
    100ber10h 100 150 24 1.5 1 41 1.253
    		12 800 20 000










    100ber10x 100 150 24 1.5 1



    		1.253
    		15 200 24 000
    105bnr10s 105 160 26 2 1 41 41 59.5 34.5 1.698 – 10 600 15 100
    105bnr10h 105 160 26 2 1 39 1.585 – 13 600 21 200











    105bnr10x 105 160 26 2 1



    		1.585 – 15 900 25 000
    105bers10s 105 160 26 2 1 39 39.5 70 43.9 1.698 – 9 100 12 900
    105ber10h 105 160 26 2 1 47.5 1.585 – 12 100 18 900











    105ber10x 105 160 26 2 1



    		1.585 – 14 400 22 700
    110bnr10s 110 170 28 2 1 46 47 68 36.7 2.133 – 10 000 14 300
    110bnr10h 110 170 28 2 1 44.5 1.996 – 12 900 20 000











    110bnr10x 110 170 28 2 1



    		1.996 – 15 000 23 600
    110bers10s 110 170 28 2 1 44 45 79.5 46.7 2.133 – 8 600 12 200
    110ber10h 110 170 28 2 1 54 1.996 – 11 500 17 900
    110ber10x 110 170 28 2 1



    		1.996 – 13 600 21 500
    120bnr10s 120 180 28 2 1 47.5 50.5 73.5 38.4 2.286 – 9 400 13 400
    120bnr10h 120 180 28 2 1 48 2.139 – 12 000 18 700











    120bnr10x 120 180 28 2 1



    		2.139 – 14 000 22 000
    120ber10s 120 180 28 2 1 45.5 48.5 86 49 2.286 – 8 000 11 400
    120ber10h 120 180 28 2 1 58 2.139 – 10 700 16 700











    120ber10x 120 180 28 2 1



    		2.139 – 12 700 20 000
    130bnr10s 130 200 33 2 1

    		89.5
    		3.408 – 8 500 12 200






    		60 61.5 58.5 43




    130bnr10h 130 200 33 2 1 3.194 – 11 000 17 000
    130ber10s 130 200 33 2 1

    		105
    		3.408 – 7 300 10 400






    		57.5 59
    		54.6




    130ber10h 130 200 33 2 1 70.5 3.194 – 9 700 15 200
    140bnr10s 140 210 33 2 1

    		97
    		3.647 – 8 000 11 500






    		62.5 66.5
    		44.6




    140bnr10h 140 210 33 2 1 63.5 3.419 – 10 300 16 000
    140ber10s 140 210 33 2 1

    		113
    		3.647 – 6 900 9 800






    		59.5 64
    		56.9




    140ber10h 140 210 33 2 1 76.5 3.419 – 9 200 14 300
    150bnr10s 150 225 35 2.1 1 73.5 78 114 47.6 4.405 – 7 500 10 700
    150bnr10h 150 225 35 2.1 1 74.5 4.129 – 9 600 15 000
    150bers10s 150 225 35 2.1 1 70 75 99.5 60.8 4.405 – 6 400 9 100
    150ber10h 150 225 35 2.1 1 90 4.129 – 8 600 13 400
    40bnr19xe 40 62 12 17 0.6 0.3 15 7.5 11.5 7.65 7.1 19.3 0.106 64 800
    40ber19xe 40 62 12 17 0.6 0.3 15 7.5 11 7.35 8.65 22.9 0.106 58 900
    45bnr19xe 45 68 12 17 0.6 0.3 15 7.5 12.1 8.7 8.1 20.2 0.128 58 500
    45ber19xe 45 68 12 17 0.6 0.3 15 7.5 11.6 8.35 9.85 24.2 0.128 53 100
    50bnr19xe 50 72 12 17 0.6 0.3 15 7.5 12.8 9.75 9.1 20.9 0.129 54 100
    50ber19xe 50 72 12 17 0.6 0.3 15 7.5 12.3 9.35 11 25.2 0.129 49 200
    55bnr19xe 55 80 13 18 1 0.6 15 7.5 14.4 11.4 10.6 22.5 0.182 48 900
    55ber19xe 55 80 13 18 1 0.6 15 7.5 13.8 10.9 12.9 27.2 0.182 44 500
    60bnr19xe 60 85 13 18 1 0.6 15 7.5 14.6 12 11.2 23.3 0.196 45 600
    60ber19xe 60 85 13 18 1 0.6 15 7.5 14 11.5 13.6 28.4 0.196 41 400
    65bnr19xe 65 90 13 18 1 0.6 15 7.5 15.2 13.2 12.3 24.1 0.209 42 600
    65ber19xe 65 90 13 18 1 0.6 15 7.5 14.5 12.6 14.9 29.6 0.209 38 800
    70bnr19xe 70 100 16 21 1 0.6 15 7.5 21.3 18.1 17.1 26.8 0.328 38 900
    70ber19xe 70 100 16 21 1 0.6 15 7.5 20.4 17.3 20.7 32.8 0.328 35 300
    75bnr19xe 75 105 16 21 1 0.6 15 7.5 21.6 19 18 27.6 0.348 36 700
    75ber19xe 75 105 16 21 1 0.6 15 7.5 20.7 18.2 21.7 34 0.348 33 400
    80bnr19xe 80 110 16 21 1 0.6 15 7.5 22 19.9 18.9 28.4 0.366 34 800
    80ber19xe 80 110 16 21 1 0.6 15 7.5 21 19.1 22.8 35.1 0.366 31 600
    85bnr19xe 85 120 18 23 1.1 0.6 15 7.5 29.4 26.3 24.8 30.7 0.506 32 200
    85ber19xe 85 120 18 23 1.1 0.6 15 7.5 28.1 25.2 30 37.9 0.506 29 300
    90bnr19xe 90 125 18 23 1.1 0.6 15 7.5 31.5 29.7 28.1 31.5 0.532 30 700
    90ber19xe 90 125 18 23 1.1 0.6 15 7.5 30 28.5 34 39.1 0.532 28 000
    95bnr19xe 95 130 18 23 1.1 0.6 15 7.5 35.5 34.5 32.5 33.3 0.589 29 400
    95ber19xe 95 130 18 23 1.1 0.6 15 7.5 34 33 39.5 41.7 0.589 26 700
    100bnr19xe 100 140 20 25 1.1 0.6 15 7.5 38 35 33 34.5 0.739 27 500
    100ber19xe 100 140 20 25 1.1 0.6 15 7.5 36 33.5 40 43 0.739 25 000
    105bnr19xe 105 145 20 25 1.1 0.6 15 7.5 41 41 39 36.5 0.758 26 400
    105ber19xe 105 145 20 25 1.1 0.6 15 7.5 39 39.5 47.5 45.9 0.758 24 000
    110bnr19xe 110 150 20 25 1.1 0.6 15 7.5 39 38 36.5 36.1 0.804 25 400
    110ber19xe 110 150 20 25 1.1 0.6 15 7.5 37.5 36.5 44 45.3 0.804 23 100
    40bnr10xe 40 68 15 20 1 0.6 15 7.5 10.6 7.95 7.5 21.2 0.217 61 200
    40ber10xe 40 68 15 20 1 0.6 15 7.5 10.1 7.65 9.1 24.9 0.217 55 600
    45bnr10xe 45 75 16 21 1 0.6 15 7.5 11.7 9 8.35 22.6 0.273 55 000
    45ber10xe 45 75 16 21 1 0.6 15 7.5 11.2 8.6 10.1 26.8 0.273 50 000
    50bnr10xe 50 80 16 21 1 0.6 15 7.5 12.2 9.9 9.2 23.4 0.296 50 800
    50ber10xe 50 80 16 21 1 0.6 15 7.5 11.6 9.5 11.1 28 0.296 46 200
    55bnr10xe 55 90 18 23 1.1 0.6 15 7.5 15.1 12.5 11.7 25.6 0.433 45 600
    55ber10xe 55 90 18 23 1.1 0.6 15 7.5 14.4 12 14.1 30.7 0.433 41 400
    60bnr10xe 60 95 18 23 1.1 0.6 15 7.5 15.6 13.7 12.8 26.5 0.463 42 600
    60ber10xe 60 95 18 23 1.1 0.6 15 7.5 15 13.1 15.5 31.9 0.463 38 800
    65bnr10xe 65 100 18 23 1.1 0.6 15 7.5 16.2 14.8 13.9 27.3 0.493 40 000
    65ber10xe 65 100 18 23 1.1 0.6 15 7.5 15.5 14.2 16.8 33 0.493 36 400
    70bnr10xe 70 110 20 25 1.1 0.6 15 7.5 22.3 19.8 18.8 29.5 0.66 36 700
    70ber10xe 70 110 20 25 1.1 0.6 15 7.5 21.3 18.9 22.6 35.8 0.66 33 400
    75bnr10xe 75 115 22 27 1.1 0.6 15 7.5 22.6 20.7 19.7 30.3 0.697 34 800
    75ber10xe 75 115 22 27 1.1 0.6 15 7.5 21.6 19.8 23.7 36.9 0.697 31 600
    80bnr10xe 80 125 22 27 1.1 0.6 15 7.5 26.5 24.5 23.4 32.5 0.939 32 200
    80ber10xe 80 125 22 27 1.1 0.6 15 7.5 25.3 23.5 28.2 39.6 0.939 29 300
    85bnr10xe 85 130 22 27 1.1 0.6 15 7.5 26.8 25.7 24.5 33.4 0.988 30 700
    85ber10xe 85 130 22 27 1.1 0.6 15 7.5 25.6 24.6 29.5 41.1 0.988 28 000
    90bnr10xe 90 140 24 29 1.5 1 15 7.5 35 33 31.5 35.7 1.25 28 700
    90ber10xe 90 140 24 29 1.5 1 15 7.5 33.5 31.5 38 43.8 1.25 26 100
    95bnr10xe 95 145 24 29 1.5 1 15 7.5 35.5 34.5 32.5 36.3 1.3 27 500
    95ber10xe 95 145 24 29 1.5 1 15 7.5 34 33 39.5 44.7 1.3 25 000
    100bnr10xe 100 150 24 29 1.5 1 15 7.5 36 36 34 37.3 1.359 26 400
    100ber10xe 100 150 24 29 1.5 1 15 7.5 34.5 34.5 41 46.2 1.359 24 000
    105bnr10xe 105 160 26 31 2 1 15 7.5 41 41 39 39.5 1.707 25 000
    105ber10xe 105 160 26 31 2 1 15 7.5 39 39.5 47.5 48.9 1.707 22 700
    110bnr10xe 110 170 28 33 2 1 15 7.5 46 47 44.5 41.7 2.139 23 600
    110ber10xe 110 170 28 33 2 1 15 7.5 44 45 54 51.7 2.139 21 500
    10bgr19s 10 22 6 0.3 0.15 2.03 0.78 0.93 5.1 0.01 100 000 138 000

    10bgr19h 10 22 6 0.3 0.15 0.61 0.009 119 000 175 000












    10bgr19x 10 22 6 0.3 0.15



    		0.009 138 000 188 000

    12bgr19s 12 24 6 0.3 0.15 2.28 0.95 1.14 5.4 0.011 88 900 123 000

    12bgr19h 12 24 6 0.3 0.15 0.74 0.01 106 000 156 000












    12bgr19x 12 24 6 0.3 0.15



    		0.01 123 000 167 000

    15bgr19s 15 28 7 0.3 0.15 3.25 1.35 1.67 6.4 0.016 74 500 103 000

    10bgr02s 10 30 9 0.6 0.3 3.6 1.33 1.62 7.2 0.032 80 000 110 000

    10bgr02h 10 30 9 0.6 0.3 1.06 0.029 95 000 140 000












    10bgr02x 10 30 9 0.6 0.3



    		0.029 110 000 150 000

    12bgr02s 12 32 10 0.6 0.3 5.3 1.99 2.46 7.9 0.036 72 800 100 000

    12bgr02h 12 32 10 0.6 0.3 1.6 0.032 86 400 128 000












    12bgr02x 12 32 10 0.6 0.3



    		0.032 100 000 137 000

    15bgr02s 15 35 11 0.6 0.3 5.8 2.34 2.9 8.8 0.045 64 000 88 000

    15bgr02h 15 35 11 0.6 0.3 1.89 0.04 76 000 112 000












    15bgr02x 15 35 11 0.6 0.3



    		0.04 88 000 120 000

    17bgr02s 17 40 12 0.6 0.3 7.25 2.98 3.65 9.8 0.065 56 200 77 200

    6bgr10s 6 17 6 0.3 0.15 1.42 0.43 0.51 4.5 0.006 140 000 192 000

    6bgr10h 6 17 6 0.3 0.15 0.34 0.005 166 000 244 000












    6bgr10x 6 17 6 0.3 0.15



    		0.005 192 000 261 000

    7bgr10s 7 19 6 0.3 0.15 1.6 0.52 0.62 4.7 0.008 124 000 170 000

    7bgr10h 7 19 6 0.3 0.15 0.4 0.007 147 000 216 000












    7bgr10x 7 19 6 0.3 0.15



    		0.007 170 000 231 000

    8bgr10s 8 22 7 0.3 0.15 2.37 0.8 0.97 5.5 0.012 107 000 147 000

    8bgr10h 8 22 7 0.3 0.15 0.63 0.011 127 000 187 000












    8bgr10x 8 22 7 0.3 0.15



    		0.011 147 000 200 000

    10bgr10s 10 26 8 0.3 0.15 3.5 1.27 1.55 6.4 0.019 88 900 123 000

    10bgr10h 10 26 8 0.3 0.15 1 0.016 106 000 156 000












    10bgr10x 10 26 8 0.3 0.15



    		0.016 123 000 167 000

    12bgr10s 12 28 8 0.3 0.15 3.85 1.48 1.8 6.7 0.021 80 000 110 000

    12bgr10h 12 28 8 0.3 0.15 1.17 0.018 95 000 140 000












    12bgr10x 12 28 8 0.3 0.15



    		0.018 110 000 150 000

    15bgr10s 15 32 9 0.3 0.15 4.2 1.72 2.12 7.6 0.029 68 100 93 700

    15bgr10h 15 32 9 0.3 0.15 1.37 0.026 80 900 120 000












    15bgr10x 15 32 9 0.3 0.15



    		0.026 93 700 128 000

    17bgr10s 17 35 10 0.3 0.15 4.45 1.93 2.39 8.5 0.038 61 600 84 700

    17bgr10h 17 35 10 0.3 0.15 1.55 0.035 73 100 108 000












    17bgr10x 17 35 10 0.3 0.15



    		0.035 84 700 116 000

    20bgr10s 20 42 12 0.6 0.3 7.45 3.35 4.1 10.2 0.066 51 700 71 000

    20bgr10h 20 42 12 0.6 0.3 2.67 0.059 61 300 90 400












    20bgr10x 20 42 12 0.6 0.3



    		0.059 71 000 96 800

    25bgr10s 25 47 12 0.6 0.3 7.9 3.75 4.65 10.8 0.076 44 500 61 200

    25bgr10h 25 47 12 0.6 0.3 3.05 0.068 52 800 77 800












    25bgr10x 25 47 12 0.6 0.3



    		0.068 61 200 83 400

    17bgr02h 17 40 12 0.6 0.3

    		2.39
    		0.057 66 700 98 300












    17bgr02x 17 40 12 0.6 0.3



    		0.057 77 200 106 000

    20bgr02s 20 47 14 1 0.6 9.7 4.1 5.1 11.5 0.103 47 800 65 700

    20bgr02h 20 47 14 1 0.6 3.3 0.091 56 800 83 600












    20bgr02x 20 47 14 1 0.6



    		0.091 65 700 89 600

    25bgr02s 25 52 15 1 0.6 11.1 5.2 6.45 12.7 0.127 41 600 57 200

    25bgr02h 25 52 15 1 0.6 4.2 0.112 49 400 72 800












    25bgr02x 25 52 15 1 0.6



    		0.112 57 200 78 000

    NN3005MBKR 25 47 16 0.6 25.8 30 0.127 900 0




    NN3006MBKR 30 55 19 1 31 37 0.198 700 200




    NN3006TBKR 30 55 19 1 31 37 0.172 0 600




    NN3007MBKR 35 62 20 1 39.5 50 0.258 500 600




    NN3007TBKR 35 62 20 1 39.5 50 0.224 600 700




    NN3008MBKR 40 68 21 1 43.5 55.5 0.309 900 700




    NN3008TBKR 40 68 21 1 43.5 55.5 0.283 800 600




    NN3009MBKR 45 75 23 1 52 68.5 0.407 500 0




    NN3009TBKR 45 75 23 1 52 68.5 0.373 200 700




    NN3010MBKR 50 80 23 1 53 72.5 0.436 600 900




    NN3010TBKR 50 80 23 1 53 72.5 0.402 100 400




    NN3011MBKR 55 90 26 1.1 69.5 96.5 0.647 400 500




    NN3011TBKR 55 90 26 1.1 69.5 96.5 0.592 800 800




    NN3012MBKR 60 95 26 1.1 73.5 106 0.693 09 700 700




    NN3012TBKR 60 95 26 1.1 73.5 106 0.635 0 0




    NN3013MBKR 65 100 26 1.1 77 116 0.741 09 100 0




    NN3013TBKR 65 100 26 1.1 77 116 0.681 400 200




    NN3014MBKR 70 110 30 1.1 94.5 143 1.06 08 400 0




    NN3014TBKR 70 110 30 1.1 94.5 143 0.988 09 500 200




    NN3015MBKR 75 115 30 1.1 96.5 149 1.11 07 900 09 500




    NN3015TBKR 75 115 30 1.1 96.5 149 1.03 09 000 600




    NN3016MBKR 80 125 34 1.1 119 186 1.54 07 400 08 800




    NN3016TBKR 80 125 34 1.1 119 186 1.44 08 300 09 800




    NN3017MBKR 85 130 34 1.1 122 194 1.63 07 000 08 400




    NN3017TBKR 85 130 34 1.1 122 194 1.52 08 000 09 400




    NN3018MBKR 90 140 37 1.5 143 0 228 2.09 6 600 7 900




    NN3018TBKR 90 140 37 1.5 143 0 228 1.93 7 400 8 700




    NN3019MBKR 95 145 37 1.5 146 0 238 2.19 6 300 7 500




    NN3019TBKR 95 145 37 1.5 146 0 238 2.03 7 100 8 400




    NN3020MBKR 100 150 37 1.5 149 0 247 2.28 6 000 7 200




    NN3020TBKR 100 150 37 1.5 149 0 247 2.12 6 800 8 000




    NN3021MBKR 105 160 41 2 192 0 310 2.88 5 700 6 800




    NN3021TBKR 105 160 41 2 192 0 310 2.69 6 500 7 600




    NN3022MBKR 110 170 45 2 222 0 360 3.71 5 400 6 500




    NN3022TBKR 110 170 45 2 222 0 360 3.44 6 100 7 200




    NN3024MBKR 120 180 46 2 233 0 390 4.04 5 000 6 000




    NN3024TBKR 120 180 46 2 233 0 390 3.75 5 700 6 700




    NN3026MBKR 130 200 52 2 284 0 475 5.88 4 600 5 500




    NN3026TBKR 130 200 52 2 284 0 475 5.47 5 200 6 100




    NN3028MBKR 140 210 53 2 298 0 515 6.34 4 300 5 200




    NN3030MBKR 150 225 56 2.1 335 0 585 7.76 4 000 4 800




    NN3032MBKR 160 240 60 2.1 375 0 660 9.41 3 800 4 500




    NN3034MBKR 170 260 67 2.1 450 0 805 12.8 3 500 4 200




    NN3036MBKR 180 280 74 2.1 565 0 995 16.8 3 300 4 000




    NN3038MBKR 190 290 75 2.1 595 1 080 17.8 3 200 3 800




    NN3040MBKR 200 310 82 2.1 655 1 170 22.7 3 000 3 600




    NN3920MBKR 100 140 30 1.1 106 182 1.32 300 500




    NN3921MBKR 105 145 30 1.1 110 194 1.5 0 200




    NN3922MBKR 110 150 30 1.1 114 207 1.41 800 0




    NN3924MBKR 120 165 34 1.1 138 251 1.99 300 400




    NN3926MBKR 130 180 37 1.5 173 325 2.64 900 900




    NN3928MBKR 140 190 37 1.5 201 375 2.97 600 500




    NN3930MBKR 150 210 45 2 262 490 4.47 200 0




    NN3932MBKR 160 220 45 2 271 520 4.75 0 800




    NN3934MBKR 170 230 45 2 280 550 5.01 800 500




    NN3936MBKR 180 250 52 2 340 655 7.76 500 200




    NN3938MBKR 190 260 52 2 345 680 7.46 400 0




    NN3940MBKR 200 280 60 2.1 420 815 10.6 200 800




    NN3944MBKR 220 300 60 2.1 440 895 11.4 900 500




    NN3948MBKR 240 320 60 2.1 460 975 12.1 700 300




    NN3952MBKR 260 360 75 2.1 670 380 21.4 500 0




    NN3956MBKR 280 380 75 2.1 695 460 22.7 300 800




    NN4920MBKR 100 140 40 1.1 155 0 295 1.76 6 300 7 500




    NNU4920MBKR 100 140 40 1.1 155 0 295 1.9 6 300 7 500




    NN4921MBKR 105 145 40 1.1 161 0 315 2 6 000 7 200




    NNU4921MBKR 105 145 40 1.1 161 0 315 1.99 6 000 7 200




    NN4922MBKR 110 150 40 1.1 167 0 335 2.1 5 800 7 000




    NNU4922MBKR 110 150 40 1.1 167 0 335 2.07 5 800 7 000




    NN4924MBKR 120 165 45 1.1 183 0 360 2.87 5 300 6 400




    NNU4924MBKR 120 165 45 1.1 183 0 360 2.85 5 300 6 400




    NN4926MBKR 130 180 50 1.5 274 0 545 3.84 4 900 5 900




    NNU4926MBKR 130 180 50 1.5 274 0 545 3.85 4 900 5 900




    NN4928MBKR 140 190 50 1.5 283 0 585 4.07 4 600 5 500




    NNU4928MBKR 140 190 50 1.5 283 0 585 4.08 4 600 5 500




    NN4930MBKR 150 210 60 2 350 0 715 6.36 4 200 5 000




    NNU4930MBKR 150 210 60 2 350 0 715 6.39 4 200 5 000




    NN4932MBKR 160 220 60 2 365 0 760 6.77 4 000 4 800




    NNU4932MBKR 160 220 60 2 365 0 760 6.76 4 000 4 800




    NN4934MBKR 170 230 60 2 375 0 805 7.13 3 800 4 500




    NNU4934MBKR 170 230 60 2 375 0 805 7.12 3 800 4 500




    NN4936MBKR 180 250 69 2 480 1 020 10.4 3 500 4 200




    NNU4936MBKR 180 250 69 2 480 1 020 10.4 3 500 4 200




    NN4938MBKR 190 260 69 2 485 1 060 10.9 3 400 4 000




    NNU4938MBKR 190 260 69 2 485 1 060 10.9 3 400 4 000




    NN4940MBKR 200 280 80 2.1 570 1 220 15.3 3 200 3 800




    NNU4940MBKR 200 280 80 2.1 570 1 220 15.3 3 200 3 800




    N1006MR1KR 30 55 13 1 0.6 .0019.7 .0019.6 0.133 19 000 31 000



    N1007mrkr 35 62 14 1 0.6 .0022.6 .0023.2 0.153 17 000 27 000



    N1008mrkr 40 68 15 1 0.6 .0027.3 .0029.0 0.192 15 000 25 000



    N1009mrkr 45 75 16 1 0.6 .0032.5 .0035.5 0.318 14 000 22 000



    N1010MRKR 50 80 16 1 0.6 .0032.0 .0036.0 0.339 13 000 20 000



    N1011bmr1kr 55 90 18 1.1 1 .0037.5 .0044.0 0.487 12 000 18 000



    N1012BMR1KR 60 95 18 1.1 1 .0040.0 .0048.5 0.519 11 000 17 000



    N1013BMR1KR 65 100 18 1.1 1 .0041.0 .0051.0 0.541 10 000 16 000



    N1014BMR1KR 70 110 20 1.1 1 .0050.0 .0063.0 0.752 09 000 15 000



    N1015mrkr 75 115 20 1.1 1 .0060.0 .0074.5 0.935 08 500 13 700



    N1016BMR1KR 80 125 22 1.1 1 .0063.5 .0082.0 1.038 07 900 12 700



    N1017BMR1KR 85 130 22 1.1 1 .0065.0 .0086.0 1.067 07 500 12 100



    N1018mrkr 90 140 24 1.5 1.1 .0088.0 114 1.2 07 000 11 400



    N1019BMR1KR 95 145 24 1.5 1.1 .0083.0 114 1.26 06 700 10 900



    N1020MRKR 100 150 24 1.5 1.1 .0093.0 126 1.32 06 400 10 400



    N1021MRKR 105 160 26 2 1.1 109 149 1.67 06 100 09 900



    N1022BMR1KR 110 170 28 2 1.1 126 173 2.07 05 800 09 300



    N1024MRKR 120 180 28 2 1.1 139 191 2.19 05 400 08 700



    N1026MRKR 130 200 33 2 1.1 172 238 3.32 04 900 07 900



    N1028BMR1KR 140 210 33 2 1.1 164 240 3.81 04 600 07 500



    N1009rstpkr 45 75 16 1 0.6 24.6 26.1 0.262 22 000 30 000



    N1009RXTPKR 45 75 16 1 0.6 24.6 26.1 0.262 25 000 42 000



    N1009RXHTPKR 45 75 16 1 0.6 24.6 26.1 0.228 29 000 50 000



    N1010RSTPKR 50 80 16 1 0.6 26.6 29.7 0.283 20 000 28 000



    N1010RXTPKR 50 80 16 1 0.6 26.6 29.7 0.283 24 000 39 000



    N1010RXHTPKR 50 80 16 1 0.6 26.6 29.7 0.246 27 000 47 000



    N1011rstpkr 55 90 18 1.1 1 35 39.5 0.372 18 000 25 000



    N1011RXTPKR 55 90 18 1.1 1 35 39.5 0.372 21 000 35 000



    N1011rxhtpkr 55 90 18 1.1 1 35 39.5 0.324 24 000 42 000



    N1012rstpkr 60 95 18 1.1 1 37.5 44 0.442 17 000 24 000



    N1012RXTPKR 60 95 18 1.1 1 37.5 44 0.442 20 000 33 000



    N1012rxhtpkr 60 95 18 1.1 1 37.5 44 0.385 22 000 39 000



    N1013rstpkr 65 100 18 1.1 1 39.5 49 0.518 16 000 22 000



    N1013RXTPKR 65 100 18 1.1 1 39.5 49 0.518 19 000 31 000



    N1013rxhtpkr 65 100 18 1.1 1 39.5 49 0.451 21 000 37 000



    N1014rstpkr 70 110 20 1.1 1 46.5 57 0.648 15 000 20 000



    N1014RXTPKR 70 110 20 1.1 1 46.5 57 0.648 17 000 28 000



    N1014rxhtpkr 70 110 20 1.1 1 46.5 57 0.564 19 000 34 000



    N1015rstpkr 75 115 20 1.1 1 49.5 63 0.672 14 000 19 000



    N1015RXTPKR 75 115 20 1.1 1 49.5 63 0.585 16 000 27 000



    N1015rxhtpkr 75 115 20 1.1 1 49.5 63 0.585 18 000 32 000



    N1016rstpkr 80 125 22 1.1 1 61.5 81.5 0.926 13 000 18 000



    N1016RXTPKR 80 125 22 1.1 1 61.5 81.5 0.926 15 000 25 000



    N1016RXHTPKR 80 125 22 1.1 1 61.5 81.5 0.812 17 000 30 000



    N1017rstpkr 85 130 22 1.1 1 65 86 0.943 13 000 17 000



    N1017RXTPKR 85 130 22 1.1 1 65 86 0.943 14 000 24 000



    N1017rxhtpkr 85 130 22 1.1 1 65 86 0.826 16 000 28 000



    50bar10s 50 80 28.5 1 0.6 14.7 27.7 18.4 25.7 0.272 600 700

    50bar10h 50 80 28.5 1 0.6 12.6 0.257 100 200

    50btr10s 50 80 28.5 1 0.6 17.4 31.5 21.5 34.1 0.272 0 100

    50btr10h 50 80 28.5 1 0.6 15.5 0.257 600 700

    55bar10s 55 90 33 1.1 0.6 18.2 35 23.4 28.9 0.412 400 200

    55BAR10H 55 90 33 1.1 0.6 16 0.391 800 500

    55btr10s 55 90 33 1.1 0.6 21.6 40 26.4 38.3 0.412 0 800

    55btr10h 55 90 33 1.1 0.6 19.7 0.391 400 200

    60bar10s 60 95 33 1.1 0.6 18.9 38 25.5 30.4 0.42 700 300

    60bar10h 60 95 33 1.1 0.6 17.5 0.397 0 600

    60btr10s 60 95 33 1.1 0.6 22.4 43.5 25.8 40.4 0.42 400 0

    60btr10h 60 95 33 1.1 0.6 21.5 0.397 700 300

    65bar10s 65 100 33 1.1 0.6 19.5 41.5 27.7 31.8 0.447 100 600

    65BAR10H 65 100 33 1.1 0.6 19 0.406 400 800

    65btr10s 65 100 33 1.1 0.6 23.1 47 27.3 42.5 0.447 900 400

    65btr10h 65 100 33 1.1 0.6 23.3 0.406 100 600

    70bar10s 70 110 36 1.1 0.6 26.9 55 37.5 34.7 0.601 400 600

    70bar10h 70 110 36 1.1 0.6 25.5 0.561 500 700

    70btr10s 70 110 36 1.1 0.6 32 63 35 46.3 0.601 300 500

    70btr10h 70 110 36 1.1 0.6 31.5 0.561 400 600

    75bar10s 75 115 36 1.1 0.6 27.3 58 39 36.1 0.634 900 0

    75BAR10H 75 115 36 1.1 0.6 26.7 0.592 0 100

    75btr10s 75 115 36 1.1 0.6 32.5 65.5 36.5 48.4 0.634 900 0

    75btr10h 75 115 36 1.1 0.6 33 0.592 900 0

    80bar10s 80 125 40.5 1.1 0.6 32 68.5 46.5 39.4 0.875 400 300

    80bar10h 80 125 40.5 1.1 0.6 32 0.821 300 300

    80btr10s 80 125 40.5 1.1 0.6 38 78 43 52.7 0.875 400 300

    80btr10h 80 125 40.5 1.1 0.6 39 0.821 400 300

    85bar10s 85 130 40.5 1.1 0.6 32.5 71.5 48.5 41.1 0.971 0 900

    85bar10h 85 130 40.5 1.1 0.6 33 0.915 0 800

    85btr10s 85 130 40.5 1.1 0.6 38.5 81.5 50.5 55.2 0.971 100 0

    85btr10h 85 130 40.5 1.1 0.6 41 0.915 0 900

    90bar10s 90 140 45 1.5 1 42.5 92.5 62.5 44.4 1.198 600 300

    90bar10h 90 140 45 1.5 1 43 1.124 400 200

    90btr10s 90 140 45 1.5 1 50 105 58 59.5 1.198 700 400

    90btr10h 90 140 45 1.5 1 52.5 1.124 600 300

    95bar10s 95 145 45 1.5 1 43 96.5 65 45.5 1.32 300 0

    95BAR10H 95 145 45 1.5 1 44.5 1.231 100 800

    95btr10s 95 145 45 1.5 1 51 110 69 61 1.32 500 100

    95btr10h 95 145 45 1.5 1 55 1.231 300 0

    100bar10s 100 150 45 1.5 1 43.5 100 68 47.3 1.399 0 600

    100bar10h 100 150 45 1.5 1 46.5 1.307 800 400

    100btr10s 100 150 45 1.5 1 51.5 114 66.5 63.7 1.399 200 800

    100btr10h 100 150 45 1.5 1 57 1.307 0 600

    105bar10s 105 160 49.5 2 1 49.5 115 78 50.6 1.74 700 200

    105BAR10H 105 160 49.5 2 1 53.5 1.624 500 0

    105btr10s 105 160 49.5 2 1 58.5 131 84 68 1.74 0 500

    105btr10h 105 160 49.5 2 1 65.5 1.624 700 200

    110bar10s 110 170 54 2 1 55.5 131 89 53.9 2.11 5 400 6 800













    110bar10h 110 170 54 2 1

    		60.5
    		1.972 6 100 7 500

    110btr10s 110 170 54 2 1 66 148 82.5 72.2 2.11 4 700 6 100













    110btr10h 110 170 54 2 1

    		74.5
    		1.972 5 400 6 800

    120bar10s 120 180 54 2 1 57 141 96 56.8 2.262 5 000 6 400













    120bar10h 120 180 54 2 1

    		65.5
    		2.114 5 700 7 000

    120btr10s 120 180 54 2 1 68 160 88.5 76.4 2.262 4 400 5 700













    120btr10h 120 180 54 2 1

    		80.5
    		2.114 5 000 6 400

    130bar10s 130 200 63 2 1 72.5 172 117 63.4 3.362 4 600 5 800













    130bar10h 130 200 63 2 1

    		79.5
    		3.148 5 200 6 400

    130btr10s 130 200 63 2 1 86 195 106 85 3.362 4 000 5 200













    130btr10h 130 200 63 2 1

    		98
    		3.148 4 600 5 800

    140bar10s 140 210 63 2 1 78.5 200 135 66.2 3.558 4 300 5 500

    140btr10s 140 210 63 2 1 93 227 84 89.1 3.558 3 800 4 900

    150bar10s 150 225 67.5 2.1 1.1 92.5 234 160 71 4.354 4 000 5 100

    150btr10s 150 225 67.5 2.1 1.1 110 267 104 95.5 4.354 3 500 4 600

    160bar10s 160 240 72 2.1 1.1 98.5 250 175 75.7 5.64 3 800 4 800

    160btr10s 160 240 72 2.1 1.1 117 284 184 101.9 5.64 3 300 4 300

    170bar10s 170 260 81 2.1 1.1 115 295 207 82.3 7.9 3 500 4 500

    170btr10s 170 260 81 2.1 1.1 136 335 220 110.5 7.9 3 100 4 000

    180bar10s 180 280 90 2.1 1.1 151 385 262 88.8 10.2 3 300 4 200

    180btr10s 180 280 90 2.1 1.1 179 440 255 118.9 10.2 2 900 3 700

    190bar10s 190 290 90 2.1 1.1 151 390 273 91.8 10.7 3 200 4 000

    190btr10s 190 290 90 2.1 1.1 179 445 281 123.2 10.7 2 800 3 600

    200BAR10S 200 310 99 2.1 1.1 169 444 300 98.3 13.8 3 000 3 800

    200btr10s 200 310 99 2.1 1.1 201 505 310 131.7 13.8 2 600 3 400

    15 TAC 47B 15 47 15 1 0.6 27.2 34 34 39.6 2.2 6 000 8 000

    17 TAC 47B 17 47 15 1 0.6 27.2 34 34 39.6 2.2 6 000 8 000

    20 TAC 47B 20 47 15 1 0.6 27.2 34 34 39.6 2.2 6 000 8 000

    25 TAC 62B 25 62 15 1 0.6 37 45 45 50.7 3 4 500 6 000

    30 TAC 62B 30 62 15 1 0.6 39.5 47 47 53.2 3.2 4 300 5 600

    35 TAC 72B 35 72 15 1 0.6 47 55 55 60.7 3.8 3 600 5 000

    40 TAC 72B 40 72 15 1 0.6 49 57 57 62.7 3.9 3 600 4 800

    40 TAC 90B 40 90 20 1 0.6 57 68 68 77.2 8.8 3 000 4 000

    45 TAC 75B 45 75 15 1 0.6 54 62 62 67.7 4.2 3 200 4 300

    45 TAC 100B 45 100 20 1 0.6 64 75 75 84.2 9.7 2 600 3 600

    50 TAC 100B 50 100 20 1 0.6 67.5 79 79 87.7 10.2 2 600 3 400

    55 TAC 100B 55 100 20 1 0.6 67.5 79 79 87.7 10.2 2 600 3 400

    55 TAC 120B 55 120 20 1 0.6 82 93 93 102.2 12 2 200 3 000

    60 TAC 120b 60 120 20 1 0.6 82 93 93 102.2 12 2 200 3 000

    15 TAC 47B DDG 15 47 15 1 0.6 25.1 30.8 36 41.8 6 000



    17 TAC 47B DDG 17 47 15 1 0.6 25.1 30.8 36 41.8 6 000



    20 TAC 47B DDG 20 47 15 1 0.6 25.1 30.8 36 41.8 6 000



    25 TAC 62B DDG 25 62 15 1 0.6 34.3 40.5 46.5 52.9 4 500



    30 TAC 62B DDG 30 62 15 1 0.6 36.8 43 49 55.4 4 300



    35 TAC 72B DDG 35 72 15 1 0.6 44.3 50.5 56.5 62.9 3 600



    40 TAC 72B DDG 40 72 15 1 0.6 46.3 52.5 58.5 64.9 3 600



    40 TAC 90B DDG 40 90 20 1 0.6 54 64 70 79.4 3 000



    45 TAC 100B DDG 45 100 20 1 0.6 61 71 77 86.4 2 600



    15TAC02AT85 15 35 11 0.6 0.3 19.5 23.5 26.5 31.9 50 8 000 10 000

    25TAC02AT85 25 52 15 1 0.6 30.5 36.6 40.4 47.4 50 5 100 7 000

    TAC35-2T85 35 90 23 1.5 1 49.7 61.4 68.6 81.9 50 3 000 4 100

    40TAC03AT85 40 90 23 1.5 1 49.7 61.4 68.6 81.9 50 3 000 4 100

    45TAC03AT85 45 100 25 1.5 1 55.8 68.6 76.4 91 50 2 700 3 700

    TAC45-2T85 45 110 27 2 1 60.3 75.6 84.5 100.9 50 2 500 3 300

    50TAC03AT85 50 110 27 2 1 60.3 75.6 84.5 100.9 50 2 500 3 300

    55TAC03AT85 55 120 29 2 1 67.1 82.7 92.3 110.1 50 2 200 3 000

    60TAC03AT85 60 130 31 2.1 1.1 72.1 89.8 100.2 119.4 50 2 100 2 800

    80tac03:00 80 170 39 2.1 1.1 94 118.5 131.5 152.5 50 1 500 2 100

    100TAC03CMC 100 215 47 3 1.1 122.5 156.9 158.1 188.1 55 1 200 1 600

    120TAC03CMC 120 260 55 3 1.1 153 189.3 190.7 223.5 55 1 000 1 300

    6000t1x ZZ Вв 10 26 8 0.3 4.55 1.87 38 900




    6200t1x ZZ Вв 10 30 9 0.6 5.1 2.39 35 000




    6001t1x ZZ Вв 12 28 8 0.3 5.1 2.37 35 000




    6201t1x ZZ Вв 12 32 10 0.6 6.8 3.05 31 900




    6301T1X ZZ Вв 12 37 12 1 9.7 4.2 28 600




    6002T1X ZZ Вв 15 32 9 0.3 5.6 2.83 29 800




    6202T1X ZZ Вв 15 35 11 0.6 7.65 3.75 28 000




    6302T1X ZZ Вв 15 42 13 1 11.4 5.45 24 600




    6003t1x ZZ Вв 17 35 10 0.3 6 3.25 27 000




    6203T1X ZZ Вв 17 40 12 0.6 9.55 4.8 24 600




    6303T1X ZZ Вв 17 47 14 1 13.6 6.65 21 900




    6004T1X ZZ Вв 20 42 12 0.6 9.4 5 22 600




    6204T1X ZZ Вв 20 47 14 1 12.8 6.6 20 900




    6005T1X ZZ Вв 25 47 12 0.6 10.1 5.85 19 500




    6205t1x ZZ Вв 25 52 15 1 14 7.85 18 200




    6305T1X ZZ Вв 25 62 17 1.5 20.6 11.2 16 100




    6006t1x ZZ Вв 30 55 13 1 13.2 8.3 16 500




    6206t1x ZZ Вв 30 62 16 1 19.5 11.3 15 300




    6306t1x ZZ Вв 30 72 19 2 26.7 14.1 13 800




    6007t1x ZZ Вв 35 62 14 1 16 10.3 14 500




    6207t1x ZZ Вв 35 72 17 1 25.7 15.3 13 100




    6307t1x ZZ Вв 35 80 21 2.5 33.5 18 12 200




    6008T1X ZZ Вв 40 68 15 1 16.8 11.5 13 000




    6208T1X ZZ Вв 40 80 18 1 29.1 17.9 11 700




    6308T1X ZZ Вв 40 90 23 2.5 40.5 22.6 10 800




    6009t1x ZZ Вв 45 75 16 1 20.9 15.2 11 700




    6209t1x ZZ Вв 45 85 19 1 31.5 20.4 10 800




    6010t1x ZZ Вв 50 80 16 1 21.8 16.6 10 800




    6210gt1x ZZ Вв 50 90 20 1 35 23.2 10 000




    6004t 20 42 12 0.6 9.38 5.03 32 000 48 000





    6204t 20 47 14 1 12.8 6.58 35 000 44 000





    6005t 25 47 12 0.6 10.1 5.85 27 000 45 200





    6205t 25 52 15 1 14 7.83 26 000 42 800





    6006t 30 55 13 1 13.2 8.27 23 000 40 000





    6206t 30 62 16 1 19.5 11.3 21 000 37 300





    6007t 35 62 14 1 16 10.3 22 000 35 800





    6207t 35 72 17 1 25.7 15.3 18 500 32 700





    6008t 40 68 15 1 16.8 11.5 21 000 32 400





    6208t 40 80 18 1 29.1 17.9 16 600 26 700





    6009t 45 75 16 1 19.9 14 18 800 29 000





    6209t 45 85 19 1 32.7 20.4 15 300 26 000





    6010t 50 80 16 1 20.8 15.4 17 300 26 700





    6210t 50 90 20 1 35.1 23.2 14 300 24 200





    6011t 55 90 18 1 28.3 21.2 16 700 23 800





    6211t 55 100 21 1.5 43.4 29.2 12 000 21 900





    6012t 60 95 18 1 29.4 23.2 15 700 21 900





    6212t 60 110 22 1.5 52.5 36 11 700 19 700





    6013t 65 100 18 1 29.2 23.5 13 300 20 600





    6213t 65 120 23 1.5 57.5 40 10 800 17 800





    6014t 70 110 20 1 38.1 30.9 11 900 18 400





    6214t 70 125 24 1.5 62 44 10 200 16 700





    6015t 75 115 20 1 37.8 31.2 11 100 17 200





    6215t 75 130 25 1.5 66 49 10 100 15 600





    6016t 80 125 22 1 47.6 39.7 10 200 15 700





    6216t 80 140 26 2 72.5 53 9 200 14 300





    6017t 85 130 22 1 47.5 40 9 500 14 700





    6217t 85 150 28 2 84 62 8 500 13 100





    6018t 90 140 24 1.5 58.2 49.6 8 700 13 500





    6019t 95 145 24 1.5 58 50 8 100 12 600





    6020t 100 150 24 1.5 60 54 7 800 12 000





    6022t 110 170 28 2 85 73 6 500 10 100





    6024t 120 180 28 2 85 80 6 100 9 400





    NN3006KR GTR3006 I 30 31.583 70 19 – M3 × 0,5 0.5




    NN3007KR GTR3007 I 35 36.667 75 20 – M3 × 0,5 0.5




    NN3008KR GTR3008 I 40 41.75 80 21 – M3 × 0,5 0.6




    NN3009KR GTR3009 I 45 46.917 85 23 – M5 × 0,8 0.7




    NN3010KR GTR3010 I 50 51.917 90 23 – M5 × 0,8 0.8




    NN3011KR GTR3011 I 55 57.167 95 26 – M5 × 0,8 0.9




    NN3012KR GTR3012 I 60 62.167 100 26 – M5 × 0,8 1




    NN3013KR GTR3013 I 65 67.167 105 26 – M5 × 0,8 1




    NN3014KR GTR3014 I 70 72.5 110 30 – M5 × 0,8 1.3




    NN3015KR GTR3015 I 75 77.5 115 30 – M5 × 0,8 1.3




    NN3016KR GTR3016 I 80 82.833 125 34 – M5 × 0,8 1.8




    NN3017KR GTR3017 I 85 87.833 130 34 – M5 × 0,8 1.9




    NN3018KR GTR3018 II 90 93.083 140 37 358 – 2.5




    NN3019KR GTR3019 II 95 98.083 145 37 363 – 2.6




    NN3020KR GTR3020 II 100 103.083 150 37 368 – 2.7




    NN3021KR GTR3021 II 105 108.417 160 41 376 – 3.5




    NN3022KR GTR3022 II 110 113.75 165 45 381 – 4




    NN3024KR GTR3024 II 120 123.833 170 46 386 – 3.9




    NN3026KR GTR3026 II 130 134.333 180 52 396 – 4.6




    NN3028KR GTR3028 II 140 144.417 190 53 406 – 5




    NN3030KR GTR3030 II 150 154.667 210 56 426 – 7




    NN3032KR GTR3032 II 160 165 220 60 436 – 7.8




    725с 1.3 -10 4 5.5 -7 7.3 12.1 -4 10.3 24.2 0 14.4

    725а 5 -3 18.5 10.3 -2 23.8 24.5 0 32.6 49 (–3) 42.5

    706c 1.5 -10 4.3 7.9 -6 8.3 15.1 -3 11.1 30.3 (–2) 15.4

    706а 4.9 -3 18.6 16.8 -1 28.7 24.4 0 32.8 48.8 (–3) 42.4

    726c 1.8 -9 5.1 9.2 -5 9.6 17.6 -2 12.8 35.2 (–3) 27.8

    726а 3.7 -3 18.4 16.2 -1 30.8 34 (–1) 40.3 68 (–4) 52.4

    707c 1.8 -9 5.1 9.2 -5 9.6 17.6 -2 12.8 35.2 (–3) 17.8

    707а 3.7 -3 18.4 16.2 -1 30.8 34 (–1) 40.3 68 (–4) 52.4

    708c 4.2 -7 7.5 14.1 -3 12.2 28.6 (–1) 16.7 57.1 (–7) 23.3

    708а 8.1 -2 26.3 24.5 0 38.8 46.4 (–2) 48.9 92.8 (–5) 63.4

    728с 4.2 -7 7.5 14.1 -3 12.2 28.5 (–1) 16.7 57 (–7) 23.3

    728а 8.1 -2 26.3 24.5 (–1) 38.8 46.4 (–2) 48.9 92.9 (–5) 63.4

    25TAC02AT85 ( 1) 1 440 520 0.113 1 960 755 0.153 2 260 950 0.175




    TAC35-2T85 2 270 705 0.266 3 100 1 020 0.36 3 550 1 280 0.415




    40TAC03AT85 2 270 705 0.266 3 100 1 020 0.36 3 550 1 280 0.415




    45TAC03AT85 2 740 775 0.355 3 750 1 120 0.48 4 300 1 410 0.55




    TAC45-2T85 3 550 880 0.52 4 850 1 270 0.705 5 600 1 600 0.81




    50TAC03AT85 3 550 880 0.52 4 850 1 270 0.705 5 600 1 600 0.81




    55TAC03AT85 4 100 945 0.65 5 600 1 370 0.88 6 500 1 720 1




    60TAC03AT85 4 750 1 020 0.81 6 450 1 480 1.1 7 450 1 850 1.25




    80tac03:00 7 350 1 270 1.55 10 000 1 840 2.1 11 500 2 330 2.45




    100tac03cmc ( 2) 1 000 830 0.105 1 400 1 240 0.147 1 600 1 575 0.166




    120tac03cmc ( 2) 1 100 930 0.12 1 500 1 378 0.163 1 800 1 775 0.196





    логотип
    Компания специализируется на производстве подшипников и предлагает подшипники всемирно известных брендов и различные аксессуары.
    +86-15221008360
    Комната 1258, № 2508, улица Сиканг, Шанхай, Китай

    СВЯЗАТЬСЯ С НАМИ

    Связаться с нами

    НАШИ ПРОДУКТЫ

    Авторские права ©2024 Фирма электронной коммерции Иу Хуайюнь. Все права защищены. | Карта сайта | политика конфиденциальности
